Some assignment highlights of the Electronics Centre – 2019
![Assembly of the test crate for the DRM2 cards at CERN [ALICE]](/elettronica/wp-content/uploads/sites/14/2020/05/Cratedi-test-delle-schede-DRM2-300x200.jpg "Assembly of the test crate for the DRM2 cards at CERN [ALICE]")
Assembly of the test crate for the DRM2 cards at CERN [ALICE]
![Test stand for the DRM2 cards development in Bologna [ALICE]](/elettronica/wp-content/uploads/sites/14/2020/05/test-di-integrazione-delle-schede-DRM2-300x200.jpg "Test stand for the DRM2 cards development in Bologna [ALICE]")
Test stand for the DRM2 cards development in Bologna [ALICE]
![Test stand for firmware development and repair of the ROD cards [ATLAS]](/elettronica/wp-content/uploads/sites/14/2020/05/Setup-di-test-e-riparazione-schede-ROD-300x200.jpg "Test stand for firmware development and repair of the ROD cards [ATLAS]")
Test stand for firmware development and repair of the ROD cards [ATLAS]
![Test setup for the OCTOPAES cards[KM3NeT]](/elettronica/wp-content/uploads/sites/14/2020/05/Setup-di-test-con-schede-OCTOPAES-300x200.jpg "Test setup for the OCTOPAES cards[KM3NeT]")
Test setup for the OCTOPAES cards[KM3NeT]
![Test setup for the OCTOPAES cards[KM3NeT] Support to the assembly of the system aimed to monitor the liqud nitrogen level into a dewar for cryogenic SiPM tests [NU@FNAL]](/elettronica/wp-content/uploads/sites/14/2020/05/sistema-di-monitoraggio-300x200.jpg "Test setup for the OCTOPAES cards[KM3NeT] Support to the assembly of the system aimed to monitor the liqud nitrogen level into a dewar for cryogenic SiPM tests [NU@FNAL]")
Support to the assembly of the system aimed to monitor the liqud nitrogen level into a dewar for cryogenic SiPM tests [NU@FNAL]
![Application of Machine Learning Algorithms in FPGA using a ATCA blade (35 x 28.5 cm2, Vadatech ATC136 modified, with Xilinx Virtex-7 FPGA and a Four core QorIQ P2040 Power PC) [CMS]](/elettronica/wp-content/uploads/sites/14/2020/05/ATCA-blade-300x200.jpg "Application of Machine Learning Algorithms in FPGA using a ATCA blade (35 x 28.5 cm2, Vadatech ATC136 modified, with Xilinx Virtex-7 FPGA and a Four core QorIQ P2040 Power PC) [CMS]")
Application of Machine Learning Algorithms in FPGA using a ATCA blade (35 x 28.5 cm2,
Vadatech ATC136 modified, with Xilinx Virtex-7 FPGA and a Four core QorIQ P2040 Power PC) [CMS]
![Setup of a Crate ATCA 14 U with Backplane 40G FullMesh [CMS]](/elettronica/wp-content/uploads/sites/14/2020/05/Crate-ATCA-300x200.jpg "Setup of a Crate ATCA 14 U with Backplane 40G FullMesh [CMS]")
Setup of a Crate ATCA 14 U with
Backplane 40G FullMesh [CMS]
Setup of a Power supply Eltek FlatpackS -48V 9kW 1U for ATCA crates
